Vintagedesign SU1

16 channel summing mixer with 2 stereo sidechains

All discrete custom design Class A inputs combined with modified Neve style B226

From the SU-1 owners manual: "SU1 is fully a discrete circuit design with two single-ended transformerbalanced class A amplifiers and 8 discrete OP amps."
